Cov khoom
Cov phuam da dej pov tseg thiab phuam tshuab
Ruian Take Off Machinery Co., Ltd. yog ib lub tuam txhab txhim khu kev qha tshaj plaws thiab cov chaw muag khoom ntawm cov phuam da dej thiab phuam da dej hauv Suav teb. Yog tias koj yuav mus yuav cov khoom siv da dej thiab phuam da dej, txais tos kom tau txais cov ntaub ntawv ntau ntxiv los ntawm peb lub hoobkas. Rau nqe kev sab laj, tiv tauj peb.
Khoom Parameter
|
Ntau lawm ceev |
80m / min (tsim), 60m / min (ruaj khov) |
|
Txoj Kev Folding |
Longitudinal M-fold + 3x cross folding rau da dej phuam; 1 x cross folding rau tes phuam |
|
Khoom siv |
Tsis yog -woven , yob txoj kab uas hla Tsawg dua los yog sib npaug li 80cm |
|
Hwj chim |
10kW, 380V / 50Hz / 3-theem 5-hlau |
|
Dimension |
5×3×2.8m (L×W×H) |
|
Qhov tseeb |
Txiav yuam kev Tsawg dua los yog sib npaug rau ± 3mm, folding precision ± 1mm |
Cov yam ntxwv ntawm cov khoom
Zog-Txuag Tsim: Txais cov zaus inverters, lub zog- txuag lub cev muaj zog, thiab cov tshuab ua kom sov kom txo tau lub zog siv (15–40kW / h), 15–20% ua haujlwm tau zoo dua li cov tshuab ua haujlwm.
Tsawg Cov Khoom Siv Hluav Taws Xob: Cov tshuab txiav txiav precision (servo lub cev muaj zog-tsav) txo cov ntaub pov tseg (cov khoom seem tsawg dua lossis sib npaug li 3%), txo cov nqi raw khoom rau cov khoom loj -.
Modular tsim: Cov khoom tseem ceeb yog ib qho yooj yim rau disassemble thiab hloov tsis muaj cov cuab yeej tshaj lij.
Tsis siv neeg lubrication system: Txo qhov hnav ntawm qhov txav mus los, ua kom lub tshuab ua haujlwm ntev.
Tus kheej- kev kuaj mob muaj nuj nqi: ceeb toom rau cov neeg ua haujlwm rau cov teeb meem tshwm sim nrog cov lej yuam kev kom daws tau sai.
Khoom siv
Kev lag luam hauv tsev so: Tsim cov khoom siv pov tseg lossis luv luv -lub sij hawm siv lub teeb PE PE los yog tsis yog - woven npuag quilt npog. Cov ntaub npog no pheej yig heev, hloov tau yooj yim thiab tuaj yeem txuag tau tus nqi ntxhua khaub ncaws. Lub tshuab no muaj cov khoom siv ceev ceev thiab ua tau raws li qhov xav tau ntawm cov tsev so loj.
Lub Tsev Haujlwm Saib Xyuas Kev Noj Qab Haus Huv: Tsim cov tshuaj tua kab mob uas tsis yog- cov ntaub npog npog rau cov neeg mob. Cov txheej txheem vuam ultrasonic tsis txhob ua cov nplaum nplaum, thiab cov npoo kaw kom tsis txhob muaj plua plav lossis cov kab mob nkag mus ntawm ob txheej, txo qhov kev pheej hmoo ntawm kev sib kis -.
Kev mus ncig thiab chaw nyob ib ntus: Tsim kom muaj kev sib haum xeeb thiab hnav cov ntaub npog me me rau kev siv ib ntus. Qhov kev xaiv folding module ua rau lub quilt npog yooj yim rau ntim. Cov khoom siv PE yog cov dej tsis muaj dej thiab tuaj yeem tiv thaiv cov ntaub pua plag sab hauv los ntawm kev xau lossis stains.
Txheej Txheem Flow
1.Unwinding:High-precision servo nro tswj nrog nws pib-deviation kho
2.Longitudinal Folding:M-folding ntawm lever mechanism rau ntau- txheej folding
3.Cutting: Servo-tsav teb cutter, SKD11 pwm steel rau 1M + cycles
4.Cross Folding: 3x nruam folding rau da dej phuam, 1x rau tes phuam
5. Tso zis: Sorting conveyor nrog batch suav muaj nuj nqi.
