Cov khoom
Kev kho mob zaj duab xis txiav tshuab
Muaj feem xyuam rau lub tshuab no
Lub tshuab yog tsim rau txhua hom ntawv, zaj duab xis, ntawv-yas composite, ntaub, tawv, PVC, tus tsiaj thiab lwm yam nruas loj truncation ntawm cov ntaub ntawv ntim.
Machine feature:
1. Nws txais PLC kov npo tswj, servo lub cev muaj zog rau kev tswj qhov ntev-ntev.
2. Nws siv pneumatic, photoelectric sensor rau kev tswj kev sib kis, nrog rau cov duab, hluav taws xob, roj ua ke, nws muaj cov haujlwm ntawm kev ua haujlwm yooj yim, siab precision, zoo stability, tsis tshua muaj suab nrov.
3. Lub tshuab no muaj lub luag haujlwm ntawm lub sijhawm hloov pauv zaus, suav tsis siv neeg, nres ua haujlwm los ntawm lub tswb nrov sib nqus hmoov nro tswj, tuaj yeem txiav vertically, txais yuav blower kom tshem tawm cov ntug khib nyiab.
4. Lub tshuab no tuaj yeem nrog 1 yob, 2 yob, 4rolls loading system.
5. Tsis siv neeg rau pem hauv ntej pub, yooj yim rau pawg pawg thiab nqa tawm.
|
Qauv |
QF-1100A4 |
QF-1400A4 |
|
Max dav ntawm master yob |
1100 hli |
1400 hli |
|
Max txoj kab uas hla ntawm master yob |
Φ1400 hli |
Φ1400 hli |
|
Min dav ntawm kev txiav |
100 hli |
100 hli |
|
Ntev ntawm kev txiav |
200-500 hli |
200-500 hli |
|
Ceev |
Tsawg dua lossis sib npaug li 200 zaug / min |
Tsawg dua lossis sib npaug li 200 zaug / min |
|
precision |
± 0.2 hli |
± 0.2 hli |
|
Tag nrho lub zog |
20 KW |
23 kWm |
|
Qhov hnyav |
2 ton |
2.5t ib |
|
Zuag qhia tag nrho (L * W * H) |
5450 * 1900 * 1400 hli |
5050 * 2200 * 1400 hli |
|
(Duab) |
||
|
Unwinder (air ncej hom) |
Sib cais nrog lub tshuab (qhov siab tshaj plaws: 1400mm ntxiv rau qhov hnyav: 2000kg) |
|
|
Guillotine Riam: siab precision cutter, tsim qauv txee |
|
|
|
Round Hniav Slitting Riam (10sets) |
|
|
|
Cov ntawv txais platform
|
(Conveyor siv lub rooj)
|
|
|
Lub rooj siv conveyor tuaj yeem xa cov ntawv txiav rau pem hauv ntej, uas yooj yim rau kev khiav lag luam thiab nqa cov ntawv los ntawm lub tshuab. Ib sab, lub rooj tuaj yeem tsis siv neeg mus raws li daim ntawv stacking qhov siab. Qhov ua haujlwm ua rau cov ntawv ntawv stacking zoo thiab yooj yim txiav. |
||
Peb qhov ADVANTAGE:
1. Kev sib cuag ntawm ob tog yuav teb tsis pub dhau 16 teev.
2. Thaum lub sij hawm warranty, Siv OFF machinery muab cov kev pabcuam cuam tshuam dawb, xws li cov khoom siv tsis zoo uas tshwm sim los ntawm kev tsim thiab tsim khoom, uas lub tuam txhab yuav ua lub luag haujlwm rau kev hloov thiab tu.
3.Tom qab lub sij hawm tas sij hawm ntawm lub warranty, peb lub tuam txhab muab cov neeg siv khoom nrog kev ua neej nyob
Kev pabcuam thiab cov khoom seem nrog tus nqi nyiam thiab ua haujlwm tau zoo nyob rau lub sijhawm ntev.
Cim npe nrov: kev kho mob zaj duab xis txiav tshuab, Suav teb, manufacturers, hoobkas, nqe
